Model | CNC 3/4/5 Axis Milling machine (BT30,Vertical machine center) |
Application | Implant plates, fixators machining |
Machinery Specification
Description | Unit | Specification | |
Table | Table size | mm | 660x400 |
Max. load capacity of table | kg | 300 | |
Trip | Ｘ、Ｙ、Ｚaxes traverse | mm | 560x420x300 |
Distance from spindle nose to table top | mm | 200-500 | |
Accuracy | Positioning accuracy | mm | 0.005/whole trip |
Repeat positioning accuracy | mm | 0.003/ whole trip | |
Spindle | Spindle speed | rpm | 15000 |
Synchronized tapping speed | rpm | 6000 | |
Spindle taper |
| (BT30)7:24 | |
Feed rate | Rapid feed rate(x、y、z) | m/min | 56/56/56 |
Max. Acceleration | G | 2.0 | |
ATC | Tool shank system |
| BT30 |
Pull studbolt type |
| P30T-1 | |
Tool magazine capacity |
| 14 | |
Max. tool length | mm | 200 | |
Max. tool diameter | mm | 80 | |
Max. tool weight | Kg | 3 | |
Tool change time(T-T) | sec | 1.1 | |
Tool change time(C-C) | sec | 1.5 | |
Motors | Spindle motor(30min/cont.) | KW | 4.8/19 |
Feed motor (x、y、z) | KW | 3.3/3.3/3.15 | |
Machine | Power requirement | V | AC380±15% |
Power capacity | KVA | 15.2 | |
Height | mm | 2600 | |
Floor space (L x W) | mm2 | 1720x2395 | |
Weight | kg | 2500 | |
NC type |
| SIEMENS828D | |
Display |
| 10.4” | |
